Additional information
| Dimensions | 160 × 40 × 160 cm |
|---|---|
| Brand | HPAG |
| Order Cod | Stroke | Closed Pin Centre | Open Pin Centres | Kg | List Each | |||
| HC1502-875 | 2" | 51 mm | 11.5” | 292 mm | 13.5” | 343 mm | 3.6 | $373.00 |
| HC1503-875 | 3" | 76 mm | 12.5” | 318 mm | 15.5” | 394 mm | 3.9 | $380.00 |
| HC1504-875 | 4" | 102 mm | 13.5” | 343 mm | 17.5” | 445 mm | 4.1 | $388.00 |
| HC1506-875 | 6" | 152 mm | 15.5” | 394 mm | 21.5” | 546 mm | 4.6 | $403.00 |
| HC1508-875 | > 8" | 203 mm | 17.5” | 445 mm | 25.5” | 648 mm | 5.1 | $411.00 |
| HC1510-875 | 10" | 254 mm | 19.5” | 495 mm | 29.5” | 749 mm | 5.7 | $422.00 |
| HC1512-875 | 12" | 305 mm | 21.5” | 546 mm | 33.5” | 851 mm | 6.2 | $432.00 |
| HC1514-875 | 14" | 356 mm | 23.5” | 597 mm | 37.5” | 953 mm | 6.7 | $447.00 |
| HC1516-875 | 16" | 406 mm | 25.5” | 648 mm | 41.5” | 1054 mm | 7.2 | $462.00 |
| HC1518-875 | 18" | 457 mm | 27.5” | 699 mm | 45.5” | 1156 mm | 7.7 | $476.00 |
| HC1520-875 | 20" | 508 mm | 29.5” | 749 mm | 49.5” | 1257 mm | 8.3 | $486.00 |
| HC1522-875 | 22” | 559 mm | 31.5” | 800 mm | 53.5” | 1359 mm | 8.8 | $554.00 |
| HC1524-875 | 24" | 610 mm | 33.5” | 851 mm | 57.5” | 1461 mm | 9.3 | $575.00 |
| HC1526-875 | 26” | 660 mm | 35.5” | 902 mm | 61.5” | 1562 mm | 9.8 | $597.00 |
| HC1527-875 | 27” | 686 mm | 36.5” | 927 mm | 63.5” | 1613 mm | 10.1 | $612.00 |
| HC1528-875 | 28” | 711 mm | 37.5” | 953 mm | 65.5” | 1664 mm | 10.3 | $616.00 |
| HC1529-875 | 29” | 737 mm | 38.5” | 978 mm | 67.5” | 1715 mm | 10.6 | $633.00 |
| HC1530-875 | 30" | 762 mm | 39.5” | 1003 mm | 69.5” | 1765 mm | 10.9 | $637.00 |
| HC1532-875 | 32” | 813 mm | 41.5” | 1054 mm | 73.5” | 1867 mm | 11.4 | $657.00 |
| HC1533-875 | 33” | 838 mm | 42.5” | 1080 mm | 75.5” | 1918 mm | 11.6 | $669.00 |
| HC1534-875 | 34” | 864 mm | 43.5” | 1105 mm | 77.5” | 1969 mm | 11.9 | $677.00 |
| HC1536-875 | 36" | 914 mm | 45.5” | 1156 mm | 81.5” | 2070 mm | 12.4 | $727.00 |
| HC1538-875 | 38” | 965 mm | 47.5” | 1207 mm | 85.5” | 2172 mm | 12.9 | $750.00 |
| HC1540-875 | 40” | 1016 mm | 49.5” | 1257 mm | 89.5” | 2273 mm | 13.5 | $771.00 |
| HC1542-875 | 42” | 1067 mm | 51.5” | 1308 mm | 93.5” | 2375 mm | 14.0 | $794.00 |
| HC1544-875 | 44” | 1118 mm | 53.5” | 1359 mm | 97.5” | 2477 mm | 14.5 | $817.00 |
| HC1546-875 | 46” | 1168 mm | 55.5” | 1410 mm | 101.5” | 2578 mm | 15.0 | $839.00 |
| HC1548-875 | 48" | 1219 mm | 57.5” | 1461 mm | 105.5” | 2680 mm | 15.5 | $860.00 |
